Enclosure not stated · 5 knobs
The Sheriff
Based on the Victory Amps V1 The Sheriff· 2 other boards clone it
- Category
- Other
- Price
- see vendorin stock
- Tags
- Victory V1
Schematic
The schematic image is on the project page. Open it at PCBWay.
Parts list 39 rows
Report a wrong parseGot parts in a drawer? See what you can build with them.
| Ref | Value | Normalized | Type | Notes |
|---|---|---|---|---|
| Resistors 12 | ||||
| ×4 | 100k | 100k | read from the schematic by eye | |
| ×3 | 220k | 220k | read from the schematic by eye | |
| ×3 | 10k | 10k | read from the schematic by eye | |
| ×2 | 47k | 47k | read from the schematic by eye | |
| ×1 | 1M | 1M | read from the schematic by eye | |
| ×1 | 68k | 68k | read from the schematic by eye | |
| ×1 | 33k | 33k | read from the schematic by eye | |
| ×1 | 22k | 22k | read from the schematic by eye | |
| ×1 | 4k7 | 4.7k | read from the schematic by eye | |
| ×1 | 2k | 2k | read from the schematic by eye | |
| ×1 | 100 | 100 | read from the schematic by eye | |
| ×1 | 47 | 47 | read from the schematic by eye | |
| Capacitors 14 | ||||
| ×4 | 100n | 100n | read from the schematic by eye | |
| ×2 | 47n | 47n | read from the schematic by eye | |
| ×1 | 10n | 10n | read from the schematic by eye | |
| ×1 | 2n2 | 2.2n | read from the schematic by eye | |
| ×1 | 4n7 | 4.7n | read from the schematic by eye | |
| ×1 | 22n | 22n | read from the schematic by eye | |
| ×1 | 220n | 220n | read from the schematic by eye | |
| ×1 | 470n | 470n | read from the schematic by eye | |
| ×1 | 1u | 1u | read from the schematic by eye | |
| ×1 | 220p | 220p | read from the schematic by eye | |
| ×1 | 330p | 330p | read from the schematic by eye | |
| ×1 | 470p | 470p | read from the schematic by eye | |
| ×2 | 10u | 10u | electrolytic, charge pump; read from the schematic by eye | |
| ×1 | 100u | 100u | electrolytic; read from the schematic by eye | |
| Diodes 6 | ||||
| ×2 | 5V1 | 5V1 | zener; read from the schematic by eye | |
| ×2 | 2V7 | 2V7 | zener; read from the schematic by eye | |
| ×1 | 6V2 | 6V2 | zener; read from the schematic by eye | |
| ×1 | 3V6 | 3V6 | zener; read from the schematic by eye | |
| ×2 | 1N4148 | 1N4148 | output clamp to rails; read from the schematic by eye | |
| ×1 | 1N5817 | 1N5817 | read from the schematic by eye | |
| ICs 2 | ||||
| ×2 | TL072 | TL072 | four sections drawn; read from the schematic by eye | |
| ×1 | TC1044SCPA | TC1044SCPA | charge pump for negative rail; read from the schematic by eye | |
| Potentiometers 5 | ||||
| Gain | A250k | A250k | Potentiometer | read from the schematic by eye |
| Treble | B250k | B250k | Potentiometer | read from the schematic by eye |
| Bass | A1M | A1M | Potentiometer | read from the schematic by eye |
| Mid | B25k | B25k | Potentiometer | read from the schematic by eye |
| Volume | B1M | B1M | Potentiometer | read from the schematic by eye |
