MT10 Mostortion
Based on the Ibanez MT10 Mostortion· 8 other boards clone it
- Category
- Distortion
- Controls
- Distortion · Mid · Treble · Bass · Level
- Price
- see vendorin stock
- Tags
- Ibanez, Ibanez, MT10, Mostortion, distortion
From the vendor
The MT-10 is part of the „Ibanez Power Series by Maxon“ and has been developed in the US in order to get an accurate emulation of a tube preamp. Therefore the MT-10 is able, to produce warm and beefy vintage overdrive sounds. The „Distortion“ knob controls the „preamp gain“. The Mostortion also features a 3-band equalizer. That means a very wide distortion spectrum with more output and a better boost quality, than many other distortion pedals. And - with the distortion knob at minimum, you can use the MT-10 as a booster – great !!
With the settings: Distortion at 60%, Bass at 25%, Middle at 100% and Treble at 35% the pedal produces nearly a Tube Screamer TS-808 sound.
Schematic
The schematic image is on the project page. Open it at PCBWay.
Parts list 34 rows
Report a wrong parseGot parts in a drawer? See what you can build with them.
| Ref | Value | Normalized | Type | Notes |
|---|---|---|---|---|
| Resistors 12 | ||||
| ×1 | 2M2 | 2.2M | read from the schematic by eye | |
| ×2 | 1M | 1M | read from the schematic by eye | |
| ×2 | 510k | 510k | read from the schematic by eye | |
| ×1 | 100k | 100k | read from the schematic by eye | |
| ×2 | 47k | 47k | read from the schematic by eye | |
| ×2 | 33k | 33k | read from the schematic by eye | |
| ×4 | 10k | 10k | read from the schematic by eye | |
| ×1 | 4k7 | 4.7k | read from the schematic by eye | |
| ×1 | 2k7 | 2.7k | read from the schematic by eye | |
| ×2 | 1k | 1k | read from the schematic by eye | |
| ×1 | 470 | 470 | read from the schematic by eye | |
| ×1 | 220 | 220 | read from the schematic by eye | |
| Capacitors 13 | ||||
| ×1 | 100u | 100u | read from the schematic by eye | |
| ×1 | 47u | 47u | read from the schematic by eye | |
| ×1 | 10u | 10u | read from the schematic by eye | |
| ×3 | 1u | 1u | read from the schematic by eye | |
| ×1 | 220n | 220n | read from the schematic by eye | |
| ×1 | 100n | 100n | read from the schematic by eye | |
| ×1 | 68n | 68n | read from the schematic by eye | |
| ×1 | 33n | 33n | read from the schematic by eye | |
| ×1 | 22n | 22n | read from the schematic by eye | |
| ×1 | 15n | 15n | read from the schematic by eye | |
| ×1 | 1n | 1n | read from the schematic by eye | |
| ×1 | 330p | 330p | read from the schematic by eye | |
| ×1 | 51p | 51p | read from the schematic by eye | |
| Diodes 2 | ||||
| ×4 | 1N4148 | 1N4148 | two series pairs in the gain-stage feedback; read from the schematic by eye | |
| ×1 | 1N4001 | 1N4001 | read from the schematic by eye | |
| Transistors 1 | ||||
| ×2 | 2SC1815 | 2SC1815 | input and output emitter followers; read from the schematic by eye | |
| ICs 1 | ||||
| ×1 | 4558 | 4558 | two sections drawn, one dual chip; read from the schematic by eye | |
| Potentiometers 5 | ||||
| Distortion | A500k | A500k | Potentiometer | read from the schematic by eye |
| Mid | A50k | A50k | Potentiometer | read from the schematic by eye |
| Treble | A250k | A250k | Potentiometer | read from the schematic by eye |
| Bass | A250k | A250k | Potentiometer | read from the schematic by eye |
| Level | B100k | B100k | Potentiometer | read from the schematic by eye |
