Enclosure not stated · 4 knobs

Carcosa Fuzz

Based on the DOD Carcosa Fuzz· 6 other boards clone it

Schematic

The schematic image is on the project page. Open it at PCBWay.

Ref	Value	Normalized	Type	Notes
Resistors 9
×4	1k	1k		read from the schematic by eye
×1	4k7	4.7k		LED current-limiting resistor; read from the schematic by eye
×1	9k1	9.1k		read from the schematic by eye
×1	47k	47k		read from the schematic by eye
×5	100k	100k		read from the schematic by eye
×4	220k	220k		read from the schematic by eye
×1	470k	470k		read from the schematic by eye
×1	510k	510k		read from the schematic by eye
×6	1M	1M		read from the schematic by eye
Capacitors 5
×1	680p	680p		read from the schematic by eye
×2	10n	10n		twin-T notch; read from the schematic by eye
×8	100n	100n		read from the schematic by eye
×1	220n	220n		read from the schematic by eye
×1	100u	100u		electrolytic; read from the schematic by eye
Diodes 2
×2	BAT41	BAT41		clipping diodes; read from the schematic by eye
×1	1N5817	1N5817		reverse-polarity protection; read from the schematic by eye
Transistors 1
×5	2N5089	2N5089		read from the schematic by eye
Potentiometers 4
Before	B100k	B100k	Potentiometer	read from the schematic by eye
After	C100k	C100k	Potentiometer	wired as variable resistor; read from the schematic by eye
Hi-Cut	A5k	A5k	Potentiometer	read from the schematic by eye
Output	A100k	A100k	Potentiometer	read from the schematic by eye
Switches 1
Mode	SPDT	SPDT		ON/ON; switches the twin-T notch filter in or out; read from the schematic by eye
