Enclosure not stated · 4 knobs
JD9 Jet Driver
Based on the Ibanez JD9 Jet Driver· 3 other boards clone it
- Category
- Other
- Price
- see vendorin stock
- Tags
- Ibanez, Ibanez, JD9, Jet Driver
Schematic
The schematic image is on the project page. Open it at PCBWay.
Parts list 34 rows
Report a wrong parseGot parts in a drawer? See what you can build with them.
| Ref | Value | Normalized | Type | Notes |
|---|---|---|---|---|
| Resistors 14 | ||||
| ×5 | 10k | 10k | read from the schematic by eye | |
| ×2 | 2k2 | 2.2k | read from the schematic by eye | |
| ×2 | 470k | 470k | read from the schematic by eye | |
| ×2 | 4k7 | 4.7k | read from the schematic by eye | |
| ×2 | 20k | 20k | read from the schematic by eye | |
| ×2 | 510 | 510 | read from the schematic by eye | |
| ×1 | 1M | 1M | read from the schematic by eye | |
| ×1 | 47k | 47k | read from the schematic by eye | |
| ×1 | 1k | 1k | read from the schematic by eye | |
| ×1 | 27k | 27k | read from the schematic by eye | |
| ×1 | 6k8 | 6.8k | read from the schematic by eye | |
| ×1 | 75k | 75k | read from the schematic by eye | |
| ×1 | 8k2 | 8.2k | read from the schematic by eye | |
| ×1 | 100k | 100k | read from the schematic by eye | |
| Capacitors 12 | ||||
| ×2 | 47p | 47p | read from the schematic by eye | |
| ×2 | 47n | 47n | read from the schematic by eye | |
| ×2 | 220n | 220n | read from the schematic by eye | |
| ×2 | 1u | 1u | electrolytic; read from the schematic by eye | |
| ×1 | 22n | 22n | read from the schematic by eye | |
| ×1 | 51p | 51p | read from the schematic by eye | |
| ×1 | 220p | 220p | read from the schematic by eye | |
| ×1 | 2n2 | 2.2n | read from the schematic by eye | |
| ×1 | 10n | 10n | read from the schematic by eye | |
| ×1 | 100n | 100n | read from the schematic by eye | |
| ×1 | 100u | 100u | electrolytic; read from the schematic by eye | |
| ×1 | 47u | 47u | electrolytic; read from the schematic by eye | |
| Diodes 2 | ||||
| ×2 | 1N914 | 1N914 | read from the schematic by eye | |
| ×1 | 1N5817 | 1N5817 | read from the schematic by eye | |
| Transistors 1 | ||||
| ×2 | 2SC1815 | 2SC1815 | read from the schematic by eye | |
| ICs 1 | ||||
| ×2 | 4558 | 4558 | four sections drawn, two dual chips; read from the schematic by eye | |
| Potentiometers 4 | ||||
| Drive | B1M | B1M | Potentiometer | read from the schematic by eye |
| Mid | B10k | B10k | Potentiometer | read from the schematic by eye |
| Tone | B10k | B10k | Potentiometer | read from the schematic by eye |
| Level | B100k | B100k | Potentiometer | read from the schematic by eye |
