Manx Loaghtan

Based on the Catalinbread Manx Loaghtan· 4 other boards clone it

Schematic

The schematic image is on the project page. Open it at PCBWay.

Check before you build · 1 value the reader of this schematic was not sure of

Ref	Value	Normalized	Type	Notes
Resistors 10
×1	47k	47k		read from the schematic by eye
×6	470k	470k		read from the schematic by eye
×4	22k	22k		read from the schematic by eye
×4	100k	100k		read from the schematic by eye
×3	130	130		read from the schematic by eye
×1	100	100		read from the schematic by eye
×2	10k	10k		read from the schematic by eye
×2	2k2	2.2k		read from the schematic by eye
×2	2M	2M		read from the schematic by eye
×2	4k7	4.7k		one JFET source, one LED resistor; read from the schematic by eye
Capacitors 8
×7	100n	100n		read from the schematic by eye
×1	?	?		first-stage collector-base cap marked only '*' (no value drawn); read from the schematic by eye
×1	1n	1n		read from the schematic by eye
×3	470n	470n		read from the schematic by eye
×4	470p	470p		read from the schematic by eye
×2	10n	10n		read from the schematic by eye
×1	4n7	4.7n		read from the schematic by eye
×1	470u	470u		electrolytic; read from the schematic by eye
Diodes 2
×4	1N4148	1N4148		read from the schematic by eye
×1	1N4001	1N4001		read from the schematic by eye
Transistors 3
×2	2N5088	2N5088		read from the schematic by eye
×2	2N2222	2N2222		read from the schematic by eye
×1	2N5457	2N5457		JFET; read from the schematic by eye
Potentiometers 4
Sustain	A100k	A100k	Potentiometer	read from the schematic by eye
Lows	A500k	A500k	Potentiometer	read from the schematic by eye
Highs	B500k	B500k	Potentiometer	read from the schematic by eye
Level	A100k	A100k	Potentiometer	read from the schematic by eye
